Rail struts

STPM (1.5 mm) spatial strut

STPM (1.5 mm) spatial strut

The spatial struts of the STPM series are used for creating carrying structures for cable tracks. The anchoring to the horizontal parts of the structure is made in com-bination with DZM STP or DZM STPU holders. Subsequently NZM and NPZM cantilevers are installed on them if needed. The end of the strut can be closed by cap 0K 2 for safety.



Product code
  • SZ ARK -227xxx
  • ZZ ARK -227xxx
  • A4 ARK -247xxx*

(*) On Request

  strut length SZ ZZ A4
STPM 200 (1,5 mm) 200 mm ARK-227020 ARK-227620 -
STPM 250 (1,5 mm) 250 mm ARK-227025 ARK-227625 -
STPM 300 (1,5 mm) 300 mm ARK-227030 ARK-227630 -
STPM 400 (1,5 mm) 400 mm ARK-227040 ARK-227640 -
STPM 500 (1,5 mm) 500 mm ARK-227050 ARK-227650 -
STPM 600 (1,5 mm) 600 mm ARK-227060 ARK-227660 -
STPM 700 (1,5 mm) 700 mm ARK-227070 ARK-227670 -
STPM 800 (1,5 mm) 800 mm ARK-227080 ARK-227680 -
STPM 900 (1,5 mm) 900 mm ARK-227090 ARK-227690 -
STPM 1000 (1,5 mm) 1 000 mm ARK-227100 ARK-227700 -
STPM 1100 (1,5 mm) 1 100 mm ARK-227110 ARK-227710 -
STPM 3000 (1,5 mm) 3 000 mm ARK-227300 ARK-227900 * ARK-247300



STPM (1.5 mm) spatial strut
STPM (1.5 mm) spatial strut
STPM (1.5 mm) spatial strut
STPM (1.5 mm) spatial strut

STPM (2.0 mm) spatial strut

  • Functional integrity
STPM (2.0 mm) spatial strut

The spatial struts of the STPM series are used for creating carrying structures for cable tracks.

The anchoring to the horizontal parts of the structure is made in com-bination with DZM STP or DZM STPU holders. Subsequently NZM and NPZM cantilevers are installed on them if needed. The end of the strut can be closed by cap 0K 2 for safety.

Product code
  • SZ ARK -227xxx
  • ZZ ARK -227xxx
  • MZ ARK -237xxx
  • A2 ARK -237xxx
  • A4 ARK -247xxx*

(*) On Request

  strut length SZ ZZ MZ A2 A4
STPM 200 (2,0 mm) 200 mm - - - ARK-237020 -
STPM 250 (2,0 mm) 250 mm - - - ARK-237025 -
STPM 300 (2,0 mm) 300 mm - - - ARK-237030 -
STPM 400 (2,0 mm) 400 mm - - - ARK-237040 -
STPM 500 (2,0 mm) 500 mm - - - ARK-237050 -
STPM 600 (2,0 mm) 600 mm - - - ARK-237060 -
STPM 700 (2,0 mm) 700 mm - - - ARK-237070 -
STPM 800 (2,0 mm) 800 mm - - - ARK-237080 -
STPM 900 (2,0 mm) 900 mm - - - ARK-237090 -
STPM 1000 (2,0 mm) 1 000 mm - - ARK-226810 ARK-237100 -
STPM 1100 (2,0 mm) 1 100 mm - - - ARK-237110 -
STPM 1200 (2,0 mm) 1 200 mm ARK-227120 ARK-227720 - ARK-237120 -
STPM 1300 (2,0 mm) 1 300 mm ARK-227130 ARK-227730 - ARK-237130 -
STPM 1400 (2,0 mm) 1 400 mm ARK-227140 ARK-227740 - ARK-237140 -
STPM 1500 (2,0 mm) 1 500 mm ARK-227150 ARK-227750 - ARK-237150 -
STPM 1600 (2,0 mm) 1 600 mm ARK-227160 ARK-227760 - ARK-237160 -
STPM 1700 (2,0 mm) 1 700 mm ARK-227170 ARK-227770 - ARK-237170 -
STPM 1800 (2,0 mm) 1 800 mm ARK-227180 ARK-227780 - ARK-237180 -
STPM 1900 (2,0 mm) 1 900 mm ARK-227190 ARK-227790 - ARK-237190 -
STPM 2000 (2,0 mm) 2 000 mm ARK-227200 ARK-227800 ARK-226820  ARK-237200 -
STPM 2100 (2,0 mm) 2 100 mm ARK-227210 ARK-227810 - ARK-237210 -
STPM 2200 (2,0 mm) 2 200 mm ARK-227220 ARK-227820 - ARK-237220 -
STPM 2300 (2,0 mm) 2 300 mm ARK-227230 ARK-227830 - ARK-237230 -
STPM 2400 (2,0 mm) 2 400 mm ARK-227240 ARK-227840 - ARK-237240 -
STPM 2500 (2,0 mm) 2 500 mm ARK-227250 ARK-227850 - ARK-237250 -
STPM 2600 (2,0 mm) 2 600 mm ARK-227260 ARK-227860 - ARK-237260 -
STPM 2700 (2,0 mm) 2 700 mm ARK-227270 ARK-227870 - ARK-237270 -
STPM 2800 (2,0 mm) 2 800 mm ARK-227280 ARK-227880 - ARK-237280 -
STPM 2900 (2,0 mm) 2 900 mm ARK-227290 ARK-227890 - ARK-237290 -
STPM 3000 (2,0 mm) 3 000 mm ARK-227302 ARK-227902 ARK-226830 ARK-237302 * ARK-247302
STPM 6000 (2,0 mm) 6 000 mm ARK-227602 - ARK-226860  - -



STPM (2.0 mm) spatial strut
STPM (2.0 mm) spatial strut
STPM (2.0 mm) spatial strut
STPM (2.0 mm) spatial strut

STNM (1.5 mm) wall strut

STNM (1.5 mm) wall strut

The struts of the STNM series are used for wall mounting of cable routes in places where the anchoring forces should be distributed in poor quality masonry.Using rectangular nuts MSM/M6-M8 and positioning clamp, it is possible to add another cable route later.

Product code
  • SZ ARK -228xxx
  • ZZ ARK -228xxx
  • A2 ARK -238xxx
  strut lenght SZ ZZ A2
STNM 200 (1,5 mm) 200 mm ARK-228020 ARK-228620 ARK-238020
STNM 250 (1,5 mm) 250 mm ARK-228025 ARK-228625 ARK-238025
STNM 300 (1,5 mm) 300 mm ARK-228030 ARK-228630 ARK-238030
STNM 400 (1,5 mm) 400 mm ARK-228040 ARK-228640 ARK-238040
STNM 500 (1,5 mm) 500 mm ARK-228050 ARK-228650 ARK-238050
STNM 600 (1,5 mm) 600 mm ARK-228060 ARK-228660 ARK-238060
STNM 700 (1,5 mm) 700 mm ARK-228070 ARK-228670 ARK-238070
STNM 800 (1,5 mm) 800 mm ARK-228080 ARK-228680 ARK-238080
STNM 900 (1,5 mm) 900 mm ARK-228090 ARK-228690 ARK-238090
STNM 1000 (1,5 mm) 1 000 mm ARK-228100 ARK-228700 ARK-238100
STNM 1100 (1,5 mm) 1 100 mm ARK-228110 ARK-228710 ARK-238110
STNM 1200 (1,5 mm) 1 200 mm - - ARK-238120
STNM 1300 (1,5 mm) 1 300 mm - - ARK-238130
STNM 1400 (1,5 mm) 1 400 mm - - ARK-238140
STNM 1500 (1,5 mm) 1 500 mm - - ARK-238150
STNM 1600 (1,5 mm) 1 600 mm - - ARK-238160
STNM 1700 (1,5 mm) 1 700 mm - - ARK-238170
STNM 1800 (1,5 mm) 1 800 mm - - ARK-238180
STNM 1900 (1,5 mm) 1 900 mm - - ARK-238190
STNM 2000 (1,5 mm) 2 000 mm - - ARK-238200
STNM 3000 (1,5 mm) 3 000 mm ARK-228300 ARK-228900 ARK-238300



STNM (1.5 mm) wall strut
STNM (1.5 mm) wall strut

STNM (2.0 mm) wall strut

  • Functional integrity
STNM (2.0 mm) wall strut

The struts of the STNM series are used for wall mounting of cable routes in places where the anchoring forces should be distributed in poor quality masonry.Using rectangular nuts MSM/M6-M8 and positioning clamp, it is possible to add another cable route later.

Product code
  • SZ ARK -228xxx
  • ZZ ARK -228xxx
  • MZ ARK -226xxx
  • A4 ARK -248xxx *

(*) On Request

  strut lenght SZ ŽZ MZ A4
STNM 200 (2,0 mm) 200 mm - - ARK-226902  -
STNM 300 (2,0 mm)  300 mm  - -  ARK-226903  -
STNM 400 (2,0 mm)  400 mm  - -  ARK-226904  -
STNM 500 (2,0 mm)  500 mm  - -  ARK-226905 -
STNM 600 (2,0 mm)  600 mm  - -  ARK-226906  -
STNM 1000 (2,0 mm) 1 000 mm  - -  ARK-226910 -
STNM 1200 (2,0 mm) 1 200 mm ARK-228120 ARK-228720 - -
STNM 1300 (2,0 mm) 1 300 mm ARK-228130 ARK-228730 - -
STNM 1400 (2,0 mm) 1 400 mm ARK-228140 ARK-228740 - -
STNM 1500 (2,0 mm) 1 500 mm ARK-228150 ARK-228750 - -
STNM 1600 (2,0 mm) 1 600 mm ARK-228160 ARK-228760 - -
STNM 1700 (2,0 mm) 1 700 mm ARK-228170 ARK-228770 - -
STNM 1800 (2,0 mm) 1 800 mm ARK-228180 ARK-228780 - -
STNM 1900 (2,0 mm) 1 900 mm ARK-228190 ARK-228790 - -
STNM 2000 (2,0 mm) 2 000 mm ARK-228200 ARK-228800 ARK-226920  -
STNM 2100 (2,0 mm) 2 100 mm ARK-228210 ARK-228810 - -
STNM 2200 (2,0 mm) 2 200 mm ARK-228220 ARK-228820 - -
STNM 2300 (2,0 mm) 2 300 mm ARK-228230 ARK-228830 - -
STNM 2400 (2,0 mm) 2 400 mm ARK-228240 ARK-228840 - -
STNM 2500 (2,0 mm) 2 500 mm ARK-228250 ARK-228850 - -
STNM 2600 (2,0 mm) 2 600 mm ARK-228260 ARK-228860 - -
STNM 2700 (2,0 mm) 2 700 mm ARK-228270 ARK-228870 - -
STNM 2800 (2,0 mm) 2 800 mm ARK-228280 ARK-228880 - -
STNM 2900 (2,0 mm) 2 900 mm ARK-228290 ARK-228890 - -
STNM 3000 (2,0 mm) 3 000 mm ARK-228302 ARK-228902 ARK-226930 * ARK-248300
STNM 6000 (2,0 mm) 6 000 mm ARK-228602 - - -



STNM (2.0 mm) wall strut
STNM (2.0 mm) wall strut
